HP5 | Window & Door Low-Pressure Gun Foam

Origin Pro™ HP5 is a professional-grade, low-pressure, one-component polyurethane foam sealant designed to fill, seal, and insulate gaps and penetrations in the building envelope. HP5 expands to seal irregular voids, helping reduce air infiltration while improving energy efficiency and moisture control.

HP5 cures to a closed-cell foam that is rigid, durable, and dimensionally stable. Once cured, the foam is non-toxic and inert, making it suitable for a wide range of residential and commercial construction applications.

Product Type: One-Component Foam (OCF)
Chemistry: Polyurethane

_______________________________________________________

KEY FEATURES & BENEFITS

• Low-pressure, one-component polyurethane foam
• Closed-cell structure for air sealing and insulation
• Excellent adhesion to common construction substrates
• Fast tack-free time for jobsite efficiency
• Cuttable in approximately one hour
• Chemically inert after cure
• Resistant to heat and cold after cure
• GREENGUARD Gold Certified for low chemical emissions
• Manufactured in compliance with BABAA, BAA, and TAA requirements

_______________________________________________________

RECOMMENDED USES

• Sealing gaps, cracks, and crevices
• Beneath base plates and mud sills
• Corner joints and exterior wall penetrations
• Around windows and doors
• Around utility panels, pipes, and duct penetrations
• General air-sealing applications in residential and commercial construction

_______________________________________________________

SUBSTRATE COMPATIBILITY / BONDS WITH

HP5 adheres to most common construction materials including:

• Wood
• Concrete and masonry
• Metal
• PVC and most plastics
• Electrical wire insulation (including Romex®)
• Rubber and polyethylene (PEX)

Note: Foam is not UV resistant. If left exposed, cured foam should be coated or painted.

_______________________________________________________

APPLICATION INSTRUCTIONS

Surfaces must be clean, dry, and free of dust, grease, loose particles, or mold release agents.

For best results, condition the product to 65–80°F (18–27°C) before use.

Attach the container to a compatible dispensing gun, shake well, and begin dispensing. Foam output may be controlled by the trigger and/or metering screw on the gun.

Foam application may be interrupted as needed. As long as the gun remains attached to a pressurized container, it will be ready for immediate re-use.

Replace empty containers with a new container.

_______________________________________________________

PHYSICAL PROPERTIES

Typical values; not for specification.

_______________________________________________________

PERFORMANCE & COMPLIANCE

• ASTM E84 / UL 723: Flame Spread Index 15, Smoke Developed 25
• CAN/ULC S102: Flame Spread Index 15, Smoke Developed 25
• Fungi Resistance: ASTM G21 – No Growth
• UL Classified (File #R13919)
• CCMC #13626-L
• NFPA 30B – Level 2 Aerosol
• VOC Content (calculated): 165 g/L (16%)
• ULE GREENGUARD Gold Certified

_______________________________________________________

YIELD (THEORETICAL) — 20 OZ NET CONTENTS

Yield values are based on 1.00 lb/ft³ density and theoretical calculations. Actual yield will vary with ambient conditions, temperature, and application technique.

Theoretical Volume: ~1.25 ft³ (≈35 L)

_______________________________________________________

TEMPERATURE PERFORMANCE

• Product Storage: Below 122°F (50°C)
• Application (Substrate): 0°F to 100°F (-18°C to 38°C)
• Chemical Temperature: 65°F to 80°F (18°C to 27°C)
• Cured Foam Service Range: -200°F to 240°F (-129°C to 116°C)

_______________________________________________________

PACKAGING

• 20 oz pressurized can
• Packaged in 12-pack cases
• For use with compatible foam dispensing guns

_______________________________________________________

STORAGE & SHELF LIFE

Store upright in a dry area. Do not expose to open flame or temperatures above 122°F (50°C).

Shelf Life: 15 months (expiration date located on container)

_______________________________________________________

SAFETY & HANDLING

• For professional use only
• Use only in well-ventilated areas
• Wear protective glasses with side shields or goggles, nitrile gloves, and clothing that protects against dermal exposure
• Avoid breathing vapors
• Avoid contact with skin and eyes
• Refer to the Safety Data Sheet (SDS) for detailed safety, handling, and disposal information
• Cured foam is non-toxic and inert. Always follow applicable local, state, and federal safety regulations.

_______________________________________________________

LIMITATIONS

• Not UV resistant — exposed foam must be protected with a coating or covering
• Not intended for continuous immersion or underwater applications
• Do not incinerate containers
• Avoid exposure to open flame or excessive heat
• Performance may vary based on substrate condition, ambient conditions, and application technique
• User is responsible for determining suitability of the product for the intended application
• Follow all applicable building codes and safety requirements

_______________________________________________________

WARRANTY

Legacy Sealants, Inc. warrants that this product meets the stated specifications when used as directed. Liability is limited to replacement of the original product.
